White FTTH Fiber Optic Fusion Protection Round Box For Drop Cable
Optic Fiber Fused
Description of goods
This is an open leather cable fusing box. The leather cable
hot-melt protection box is made of a heat-shrinkable protection
tube to complete the hot-melt, and the optical cable is put into it
to better protect the melting point. Compared with the
cold-connected product, it can improve the optical performance of
the connector, thereby increasing the effective splicing rate. ,
prolong the service life of the product and reduce the maintenance
cost in the later period.
Advantages
1. The Heat-Shrink Protection Sleeve is completely built into the
FTTH Fiber Optic Fusion Protection Round Box , which improves the
reliability of the product.
2. The whole process of jointing is visible, and the product
jointing qualification rate is greatly increased, which saves the
construction time effectively.
3. The fusion splicing of optical cables can achieve high optical
performance with an average insertion loss of ≤ 0.03B and a return
loss of ≥ 60dB.
4. The products are not affected by the environment during using,
with no failure rate and long service life, reducing post
maintenance costs.
5. The unique fiber tightening structure at the end of the cable
makes the tensile strength of the cable greater than 60N.
6. The operation is very easy, and professional skills are
unnecessary require for the operating workers.
Usage method
First, please fix the heat shrinkable tube in the protective box;
next, tighten the round protective cover.
Product Features
1. Made of high-quality plastic, the joints are firm and neat;
2. High corrosion resistance, anti-aging and anti-stretching
ability;
3. White and smooth, long service life, not suitable for
deformation, not easy to yellow;
4. The heat-shrinkable sleeve protection after the leather rope and
pigtail are welded.
| Material | ABS EVA |
| Operating temperature | -40℃-75℃ |
| Applicable optical fiber | 10.2cm*1.2cm*1.0cm |
| Feature | Waterproof |
